Microtest 6632 Empedance Analyzer Frequency range : DC, 10Hz to 1/3/5/10/20/30MHz/50MHz

Açıklama

Frekans aralığı: DC, 10Hz – 1/3/5/10/20/30MHz/50MHz
±%0,08’e kadar temel doğruluk (tipik ±%0,05)
Otomatik Seviye Kontrolü (ALC)
Çıkış empedansı 25Ω/100Ω, değiştirilebilir
Destek metre modu ve liste modu, süpürme modu
Eşdeğer Devre Analizi
Dahili DC Bias Gerilimi ±12V
Ultra yüksek ölçüm hızı < 3ms
Açık devre/kısa devre/yük düzeltme fonksiyonu
Karşılaştırıcı işlevi
BIN sınıflandırma işlevi
Dahili Geçirgenlik-μr
Dahili Dielektrik sabiti-εr

Specifications

Selection

Model

6632-1

6632-3

6632-5

6632-10

6632-20

6632-30

6632-50

Frequency

10Hz-

1MHz

10Hz-

3MHz

10Hz-

5MHz

10Hz-

10MHz

10Hz-

20MHz

10Hz-

30MHz

10Hz-

50MHz

Equivalent Circuit Analysis

6632-1S

6632-3S

6632-5S

6632-10S

6632-20S

6632-30S

6632-50S

SPEC

Model	6632
Frequency Range	10Hz-50MHz
Frequency Setting	Continuity
Frequency Resolution	100mHz, 6-bit Frequency Input
Frequency Output Accuracy	±0.01%
Basic Accuracy	±0.08% (typical ±0.05%)
AC Drive Level	Test Signal Voltage Level	10mV – 2Vrms(100Ω) 10mV – 1Vrms(25Ω)
	Voltage Minimum Resolution	1mV
	Accuracy	ALC ON：6％ * Voltage ±2mV ALC OFF：10％ * Voltage ±2mV
	Test Signal Current Level	200µA – 20mArms
	Current Minimum Resolution	10µA
	Accuracy	ALC ON：6％ * Current ± 20µA ALC OFF：10％ * Current ± 20µA
DC Drive Level	1V (fixed)
Output Impedance	25Ω/100Ω (switchable)
DC Bias Voltage	Built-in ±12V (100Hz-50MHz)	External Voltage Bias (±12V/±40V/±2000V)
DC Bias Current	Option DC Bias Current Source (20A/60A/120A/320A)	External Voltage Bias (100mA/1A)
Measurement Mode	Meter mode, list mode, sweep mode, and optional equivalent circuit analysis function (S model)
Measurement Parameters	\|Z\|、\|Y\|、θ、X、R、G、B、L、D、Q、DCR、C、 ESR、εr 、μr
Test Time (Fastest)	< 3mS

Measurement Parameters

Parameters	Range
\|Z\|	0.000 mΩ to 9999.99 MΩ
R, X	± 0.000 mΩ to 9999.99 MΩ
\|Y\|	0.00000 μS to 999.999 kS
G, B	± 0.00000 μS to 999.999 kS
θRAD	± 0.00000 to 3.14159
θDEG	± 0.000° to 180.000°
Cs, Cp	± 0.00000 pF to 9999.99 F
Ls, Lp	± 0.00 nH to 9999.99 kH
D	0.00000 to 9999.99
Q	0.00 to 9999.99
Δ	± 0.00% to 9999.99%
Rdc	0.00 mΩ to 99.9999 MΩ
εr’ εr”	0 to 100000
μr’ μr”	0 to 100000

System

Measurement Circuit	Series/Parallel
Correction	Open Circuit/Short Circuit/Load correction
Cable Compensation	0 / 0.5 / 1 /2 (m)
BIN	ABS、ΔABS、Δ%、OFF
Comparator	9
List Mode	50 groups of Multi-steps setting (Each group contains up to 15 steps)
Bulit-in Storge	100 sets LCR setting documents, 50 groups of list mode setting
USB Host Storge	LCR setting documents, list mode setting document, BMP graphics, Sweep screen and test result data
Trigger Test	Auto, manual, RS-232, GPIB, Handler
Power Supply	Voltage：90-264Vac
Power Supply	Frequency：47-63Hz
Power consumption	30VA
Environment	Temperature：10℃-40℃
Environment	Humidity：20-90%RH
Dimension	336x147x340 mm (WHD)
Weight	3.95 Kg
Interface	RS-232、Handler、LAN、USB Host、USB Device
Display	Color Screen, 7″ TFT (800*480)
